At the receiver side we employ sampling, quantizing, encoding. Generally the two process named as encoding and quantizing are done in the same circuit known as analog to digital converter i.e. A to D converter. The operations done in the receiver circuit are regeneration of the received signal, decoder,.
y = uencode(u,n)
quantizes the entries ina multidimensional array of floating-point numbers u
andencodes them as integers using 2n-levelquantization. n
mustbe an integer between 2 and 32 (inclusive). Inputs can be real orcomplex, double- or single-precision. The output y and the input u
arearrays of the same size. The elements of the output y are unsignedintegers with magnitudes in the range [0, 2n-1].Elements of the input u
outside of the range [-1,1]
aretreated as overflows and are saturated.
For entries in the input
u
thatare less than -1, the value of the output ofuencode
is0.For entries in the input
u
thatare greater than 1, the value of the output ofuencode
is2n-1.
y = uencode(u,n,v)
allowsthe input u
to have entries with floating-pointvalues in the range [-v,v]
before saturating them(the default value for v
is 1).Elements of the input u
outside of the range [-v,v]
aretreated as overflows and are saturated:
For input entries less than -
v
,the value of the output ofuencode
is 0.For input entries greater than
v
,the value of the output ofuencode
is 2n – 1.
Matlab Program For Uniform Quantization Encoding Failure Definition
y = uencode(u,n,v,
mapsentries in a multidimensional array of floating-point numbers 'SignFlag'
)u
whoseentries have values in the range [-v,v
] to an integeroutput y
. Input entries outside this range aresaturated. The integer type of the output depends on the number ofquantization levels 2n andthe value of 'SignFlag'
, which can be oneof the following:
'signed'
: Outputs are signed integerswith magnitudes in the range [-2n/2, (2n/2) – 1].'unsigned'
(default): Outputs areunsigned integers with magnitudes in the range [0, 2n – 1].
The output data types are optimized for the number of bits asshown in the table below.
n | Unsigned Integer | Signed Integer |
---|---|---|
2 to 8 | ||
9 to 16 | ||
17 to 32 |
